GL-FS610w-dt-LFM610s/ln

Description

• Features

  • The internal adopts full copper radiator large area, good heat dissipation, ensure the lifespan of the LED Lamps;
  • Through efficient optical lenses, with special heat dissipation design, make the light is downy, small stray light, no glare, eyes more comfortable;
  • Use the LED, the light energy saving 80%;
  • Because of almost no infrared radiation, it has greatly improve work environment.

  Technical Specifications

  Light Sources

  • LED: high brightness 600W LED lamp
  • Lifespan: 50000h
  • Color: seven color + white changeable, by color wheel
  • Color temperature: 7500-8000K

  Optics

  • Beam angle: 7-13°
  • Color wheel: seven color+ white
  • Color temperature wheel: 3200K+4500K+5600K
  • Dimmer: 0-100% linear dimmer
  • Strobe: 1-20 times/second

  Light Output

  • Optimal projection distance: 4-600m

  Control

  • Control mode: DMX-512; Manual
  • DMX channel: 5CH
  • Display of control panel: LCD display + 4 buttons

  Power Supply

  • Related voltage: AC100V-240V, 50/60Hz
  • Related power: 680w

  Construction

  • Body dimension: 775*263*213mm
  • Net weight: 17.5kg
  • Shell color: black
  • Shell material:aluminiumdie casting

  Working Environment

  • Working temperature: -25-40
  • Cooling: Fan+ aluminum radiator
  • Protection rating: IP20

  Standard Configuration Spare Part List

  • Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)
  • User manual: English version user manual
  • Tripods: 1pc

  Optional Configuration Spare Parts List

  • Clamps: different style clamps optional (choose from HMII homepage “Accessaries series”)
  • Safety rope: different size safety ropes optional (choose from HMII homepage “Accessaries series”)

  Package

  • Carton board box package size: 1028*208*336mm(1pc/carton)
  • N.W/G.W/V.W: 17.5kg/20kg

  Selling Maintain Spare Parts List

  • Switching power supply: VG-LFL600-P
  • LED lamp board: VG-LFL600-L
  • Main board: VG-LFL600-M

  ·Drive board: VG-LFL600-D
